ITC TV-61W Omnidirectional Microphone for Video Conference
ITC TV-61W Omnidirectional Microphone for Video Conference

ITC TV-61W Omnidirectional Microphone for Video Conference

Model NO.
TV-61W
Delivery
FOB
Minimum order quantity
10 pieces
Supply Ability
30 pieces / Week
Country of Origin
Guangzhou, Shenzhen and HK
Quantity:
  • Place of Origin:CN;GUA
  • Brand Name:ITC
  • Use:Conference Microphone
  • Communication:WIRED
  • Model Number:TV-61W
  • Style:Desktop
  • Cancellation depth of full duplex echo:≥65dB
  • Cancellation time of full duplex echo:500ms
  • Bidirectional noise compression:≥18dB
  • Cancellation depth of line echo:≥25dB
  • Cancellation time of line echo:32ms
  • Frequency response of microphone:≥65dB
  • Pick-up range of microphone:500ms
  • Pick-up angle of microphone:≥18dB
  • Quantity of microphone:≥25dB
  • Frequency response of speaker:32ms
Product Description

1) Using dual core DSP audio processor; basic frequency is up to 1.4GHz; achieve industrial quality;
2) Sampling rate is 48KHz; frequency response is 100Hz to 22KHz; so that TV-61W could collect voice and music signal perfectly;
3) Digital signal processing and transmission technique; TV-61W enhances the sound quality via echo canceler, auto gain control, dynamic noise compressor and intelligent microphone algorithm;
4) With dual channel sampling to provide users with hifi stereo audio;
5) All in 1 design and minimalist structure;
6) With 4 array style digital microphone; omnidirectional pick-up, and the distance is up to 3 meters;
7) With 1 10W hifi speaker, the volume is up to 95dB with 12 stage adjustment;
8) With 1 USB port to seamlessly link video conference system, multimedia communication system, UC platform, VPN platform, etc;
9) With 2 audio input in type of 3.5mm jack and 2 audio output in type of 3.5mm jack, which could seamlessly work with video conference system, sound reinforce system, etc.

Acoustics Feature
Acoustics Feature
Cancellation depth of full duplex echo
≥65dB
Cancellation time of full duplex echo
500ms
Bidirectional noise compression
≥18dB
Cancellation depth of line echo
≥25dB
Cancellation time of line echo
32ms
Audio Feature
Audio Feature
Frequency response of microphone
≥65dB
Pick-up range of microphone
500ms
Pick-up angle of microphone
≥18dB
Quantity of microphone
≥25dB
Frequency response of speaker
32ms
Speaker volume
Max. 95dB
Speaker volume level
12 level
Quantity of speaker
1
Interface Feature
Interface Feature
USB Output
USB port x1
Audio Input
3.5mm jack x2
Audio Output
3.5mm jack x2
Tel. Communication Output
RJ11 x1
Electrics Feature
Electrics Feature
Power Supply
AC 110V to AC 220V (50 - 60Hz)
Max. Power Consumption
12W
Working Environment
Working Environment
Reverberation time
<0.5s
Noise level
<-48dBA
Venue area
≤30 square meters or ≤10 people
Physical Feature
Physical Feature
Color
Titanium argent
Working Temp.
0℃ to 50℃
Working Humidity
20% to 85%
Dimension (LxWxH)
30.5x30.5x6.6cm
Weight
3.6Kg
