ITC T-210BM 10W 2.4G Multimedia Active Radio Speaker With Wireless Microphone

ITC T-210BM 10W 2.4G Multimedia Active Radio Speaker With Wireless Microphone

Model NO.: T-210BM T-220BM
Delivery: FOB
Minimum order quantity: 500 units
Supply Ability: 1000 units / Month
Country of Origin: Guangzhou, Shenzhen or HK

Quantity:

Product Description

Place of Origin:CN;GUA
Use:Home Theatre
Model Number:T-210BM T-220BM
Brand Name:ITC
Type:Active
Channels:2 (2.0)
Special Feature:Wireless
Use:Public Address
Rated Power:20W x2
Output Impedance:4 ohm
Input Sensitivity:Line In: 350MV±20MV; Mic: 5MV±0.5MV; Line Out: 1V±0.5V;
Input:Line Input x2; Mic Input x2; Line Output x1
S/N Ratio:≥70dB
Frequency Response:20 to 20KHz (±3dB)
Volume Control:1 total volume control, 1 Mic volume control, 1 Line volume control
T.H.D.:≤1%
Power Supply:AC 220V/50Hz
Working Temp.:5℃ to 40℃

Application

Suitable for multimedia classroom, normal classroom, conference room, training room, brand shop, etc.

Feature

1) Transmission Frequency: 2.4 to 2.483MHz, Hifi, anti-interference;
2) Using sampling rate in highest industrial level: up to 64K@16bitx2, HDCD;
3) Sound delay＜0.5ms;
4) Frequency response: 20 to 20KHz;
5) When turned on, the speaker enters auto pairing state; after paired, the speaker enters receiving state;
6) The transmission distance between wireless receiving module and the wireless mic≤3m, and the connecting time≤1s;
7) With fixed ID; support matching of point-to-point or point-to-group; to realize encrypted transmission;
8) The 2.4G wireless mic is with volume control;
9) The 2.4G wireless mic is with rechargeable battery 3.7V/890mA, and it could work for 48 hours continuously. the standby time is up to 15 days;
10) The 2.4G wireless mic is with MP3 player and 2G memory, and it could be expanded via TF card (support up to 16G);
11) With 2 Mic input and 2 stereo line input;
12) With 1 Line output to be connected with other sound reinforce device;
13) With protection function for overload, over-voltage, and short;
14) With hifi speaker, and the rated power is 10W x2 and 20W x2 at 4ohm (the amplifier is in main speaker, and 1 10W/20W Line output at 4ohm is transmitted to deputy speaker);
15) With mute function, when Mic input is in the range from 1 to 1.5mV, the Mic input overrides Line input;
16) With 1 total volume control, 1 volume control for mic, 1 volume control for Line input, and 2 treble/bass control;

Technical Parameters

Model	T-210BM	T-220BM
Rated Power	10W x2	20W x2
Output Impedance	4 ohm
Input Sensitivity	Line In: 350MV±20MV; Mic: 5MV±0.5MV; Line Out: 1V±0.5V;
Input	Line Input x2; Mic Input x2; Line Output x1
S/N Ratio	≥70dB
Frequency Response	20 to 20KHz (±3dB)
Volume Control	1 total volume control, 1 Mic volume control, 1 Line volume control
T.H.D.	≤1%
Power Supply	AC 220V/50Hz
Working Temp.	5℃ to 40℃
Working Relative Humidity	20% to 80%, no condensing
Power Consumption	≤30W
Dimension	191x280x178mm
Weight	5.75Kg
