- Place of Origin:CN;GUA
- Simultaneous Interpretation:Yes
- Function:translation
- Model Number:TS-0670HS
- Brand Name:ITC
- Type:Audio Conference System
- Power Supply:~110V/60Hz or ~230V/50Hz
- Power rating:36W
- Frequency range:2 ~ 6 MHz
- Infrared Radiation Power:33 w
- RF output impedance:75Ω
- RF input:100MV - 3V 10 KΩ
- Gain control:AGC automatic gain control
- Automatic threshold control:100MV RF signal to start
- Standby power consumption:3W
- Dimension:478 x 228 x 208mm
ITC TS-0670HS Infrared Wireless Simultaneous Translation Equipment Radiator
TS-0670HS infrared radiation Radiator is a high power infrared radiation equipment, used to receive the infrared emission host carrier signal, and emit the signal to the wireless interpretation IR receiver. Can cascading connect 30 IR Radiator at the same time.
* Super emissive power, maximum distance reach 40 meters, cascade connect with each other can achieve 500m transmission distance.
* Launch Angle: + 135°.
* Compensation function of cable delay.
* Auto standby: standby when the IR Radiator have no signal input and output.
* Reduce the signal power by half for power saving in small space.
* Adopt the arc structure with big angle and wide coverage.
Model | TS-0670HS |
Power Supply | ~110V/60Hz or ~230V/50Hz |
Power rating | 36W |
Frequency range | 2 ~ 6 MHz |
Infrared Radiation Power | 33 w |
RF output impedance | 75Ω |
RF input | 100MV - 3V 10 KΩ |
Gain control | AGC automatic gain control |
Automatic threshold control | 100MV RF signal to start |
Standby power consumption | 3W |
Dimension | 478 x 228 x 208mm |
Weight | 7.0 Kg |
Color | Black |
ITC Audiovisual is the pioneer of Chinese audiovisual industry. Latest, we launch Luna Cloud-based Public Address System. Also, we develop steadily. We provide our client with one stop
solution, such as Public Address System,IP System,conference system,video conferencing,Evacation System, professional sound system, Led video wall and Lighting system , etc.
What's more,our system is applied to various worldclass events, such as 2008 Peking Olympic
Games, 2010 Shanghai Expo, 2010 Guangzhou AsianGames, etc. For now,we have up to 600 thousand successful cases in China and in worldwide.
Q1: Are you manufacturer or trade company? Where?
A: We are manufacturer. which located in NO. 1 Building B Block Zhongcun Street Panyu District Guangzhou, Guangdong, China.
Q2: Do you offer OEM&ODM service?
A: Yes, we do.
Q3: What's the quality standard of your products?
A: Our products has approved CCC, ISO9001, CE, RoHS, EN54-24 and EN54-16 certification.
Q4: Which place will use ITC equipment?
A: Our products are widely used in International Conference, Governments, Banks, Churches, Highways, Airports, Parliaments, Eduction institutes, Hotel, Private corporate conference hall and ect.
Q5: What project you have done in overseas?
A: *EXPO 2016 Antalya in Turkey
*International Airpport in Tabatinga, Brazil.
*The 7th South China Sea International Conference in Vietnam.
*The Subway center of Chanakyapri in New Delhi, India .
*Department of Public Works and Highway in Philippines.
Q6: How to contact us?
A: Write down what you need and click Send, you will get the feedback soon.
