- Place of Origin:CN;GUA
- Model Number:T-531B
- Brand Name:ITC
- Communication:Wireless
- Style:Lavaliar
- Receiver mode:Bouble-conversion superheterodyne
- IF frequency:110MHz, 10.7MHz
- Wireless Interface:BNC / 50 ohm
- Sensitivity:12 dBμV (80dBS / N)
- Sensitivity adjustment range:12-32 dBμV
- Spurious suppression:≥75dB
- Output socket type:Balanced and unbalanced
- Maximum output level:+10 dBV
- Power supply:DC 12 ~ 18V 500mA
- Working temperature:-40 ℃ ~ - + 80 ℃
ITC T-531B 1 Channel UHF Professional Teaching Wireless Microphone with LCD
ITC T-531B 1 Channel UHF Professional Teaching Wireless Microphone with LCD
ITC T-531B 1 Channel UHF Professional Teaching Wireless Microphone with LCD
* Adopt international standard EIA 1/2 width 1U high metal chassis, which can be mounted directly to the rack.
* Provide 640-857MHZ six frequency bands 100 each, and the use of advanced phase- locked loop PLL frequency synthesizer technology, adjustable frequency, adjustable transmit power to avoid interference frequency.
* Super anti-jamming capability, can effectively suppress the noise caused by external interference and co-channel interference.
* LCD display window, displaying the channel / frequency, RF signal strength, AF audio output intensity.
* With infrared frequency transmitter frequency locked automatically synchronize ACT function.
* Rear receiving antenna separation design, single-antenna diversity receiver and the sound code, noise lock dual mute circuit, receiver distance, easily dropped.
* Internal SQ can increase receiver sensitivity adjustment to increase or decrease the sensitivity of the receiving distance in order to avoid noise interference.
ITC T-531B 1 Channel UHF Professional Teaching Wireless Microphone with LCD
Receiver Specifications | |
Receiver mode | Bouble-conversion superheterodyne |
IF frequency | 110MHz, 10.7MHz |
Wireless Interface | BNC / 50 ohm |
Sensitivity | 12 dBμV (80dBS / N) |
Sensitivity adjustment range | 12-32 dBμV |
Spurious suppression | ≥75dB |
Output socket type | Balanced and unbalanced |
Maximum output level | +10 dBV |
Power supply | DC 12 ~ 18V 500mA |
Working temperature | -40 ℃ ~ - + 80 ℃ |
Dimensions | (W x H x D) 210 mm x 44 mm x 147 mm |
ITC T-531B 1 Channel UHF Professional Teaching Wireless Microphone with LCD
System Specifications | |
Frequency Range | UHF 640-857MHz total of six segments |
Modulation | Wideband FM |
Adjustable range | 25MHz |
The number of channels | 600 |
Channel spacing | 250KHZ |
Frequency stability | ± 0.005% or less |
Dynamic range | 100dB |
The maximum deviation | ± 45KHZ |
Audio response | 60HZ-18KHZ (± 3dB) |
Integrated SNR | >115dB |
Comprehensive distortion | ≤0.5% |
Working distance | 50 meters |
ITC T-531B 1 Channel UHF Professional Teaching Wireless Microphone with LCD
Microphone Specifications | |
Ondo | Dynamic microphone. |
Condenser | Lavalier microphone, headset microphone |
Antenna | built-in helical antenna handheld microphone, transmitter |
Peigua 1/4 wave whip-like antennas. | |
Output power | High power 30mW; low power 3mW |
Discrete suppression | -60dB |
Power supply | 2 AA 5th batteries |
Time | More than 10 hours at 30mW, more than 15 hours at 3mW |
