Powerful TR Series Hifi Professional High Power Amplifier Audio
Powerful TR Series Hifi Professional High Power Amplifier Audio
Powerful TR Series Hifi Professional High Power Amplifier Audio
Powerful TR Series Hifi Professional High Power Amplifier Audio
Powerful TR Series Hifi Professional High Power Amplifier Audio
Powerful TR Series Hifi Professional High Power Amplifier Audio
Powerful TR Series Hifi Professional High Power Amplifier Audio
Powerful TR Series Hifi Professional High Power Amplifier Audio
Powerful TR Series Hifi Professional High Power Amplifier Audio

Powerful TR Series Hifi Professional High Power Amplifier Audio

Model NO.
TR-800A Series
Delivery
FOB
Minimum order quantity
100 pieces
Supply Ability
3000 pieces / Week
Country of Origin
Guangzhou, Shenzhen and HK
Quantity:
  • Place of Origin:CN;GUA
  • Model Number:TR-800A Series
  • Brand Name:ITC
  • Stereo/Parallel 8Ωx2:1200W x2
  • Stereo/Parallel 4Ωx2:1800W x2
  • Bridged 8Ω:3600W x2
  • Connector:XLR, TRS
  • Voltage Gain (@1KHz):40dB
  • Input Sensitivity:0dBu(1V)
  • Input Impedance:10KΩ unbalanced, 20KΩ balanced
  • Frequency Response (≤1W):20 to 20KHz/±1dB
  • THD+N:≤0.05%
  • SNR (A Weighted):≥95dB
Feature

TR Series Soft Start Hifi Professional High Power Amplifier Audio

1) In 1U design, using technique of class TR real-time power tracking amplifier, high performance amplifier circuit design, hifi sound quality to restore the quality of audio sources perfectly;


2) Supportsoft-startto avoid causing interference to other devices, when it's turned on and absorbs large current;


3) With intelligent clipping distortion and over-current pressure limit system;


4) With 30/50Hz high pass filter;


5) With autotemperature control fan cooling system;


6) Multiple modes: stereo, bridged and parallelism;


7) Complete and reliable safety precautions, working mode indicators and multiple detection system for over-heat, over-pressure, low-voltage, overflowing, short, etc.

Technical Parameters
Output Power
(20 to 20KHz/THD≤1%)
TR-800A
TR-1000A
TR-1200A
Stereo/Parallel 8Ωx2
800W x2
1000W x2
1200W x2
Stereo/Parallel 4Ωx2
1200W x2
1500W x2
1800W x2
Bridged 8Ω
2400W x2
3000W x2
3600W x2
Connector
XLR, TRS
Voltage Gain (@1KHz)
38dB
39dB
40dB
Input Sensitivity
0dBu(1V)
Input Impedance
10KΩ unbalanced, 20KΩ balanced
Frequency Response
(≤1W)
20 to 20KHz/±1dB
THD+N
≤0.05%
SNR (A Weighted)
≥90dB
≥90dB
≥95dB
Damping Factor
(@1KHz)
≥200 @8ohm
Separating Degree
(@1KHz)
≥70dB
Protection
Over-pressure, low-voltage, overflowing, short, DC protection
Indicators
Power, temp. Protection, overflowing protection, clipping distortion, short protection, etc
Cooling Method
Fan cooling
Power Supply
AC 220V to AC 240V 50/60Hz
Power Consumption
2800W
3300W
4000W
Dimension (LxWxH)
483x390x44mm
Weight
8Kg
8.2Kg
8.5Kg
Our Company

Guangzhou ITC Electronic Technology Limited
* Operate a 30,000sqm factory
* 15 years of audiovisual experience
* Integrating research, production, sales and service
* 10 major product series and 1,000+ models
* Support OEM & ODM service

Packaging & Shipping
* We have very strict quality control system.
* We promise the electronics yearly failure rate is less than 1%.
* 100% products need to be aged (full loading) at least 24 hours and tested 4 times before delivery.

Exhibitions
Buy now, we have been successfully conducting both import and export activities worldwide for 10 years with suppliers and buyers.

Certifications

We have 50 software copyright and 12 patents
Product complied with certificates:
CE Certificate
ISO9001, ISO14001, IS018001, ISO27001
CCC Certificate: China Compulsory Certification
International Standard Product Making Certificate

Project Reference
Our Service

Pre-sale Service
High Quality + Factory Price + Quick Response + Reliable Service, is our working faith.
Professional foreign trade team, Reply your Alibaba enquiry and trade messager in 24 working hours.
30 system consultants and 10 designers to make drawing and BOQ for each tender.
Design and BOQ response to customer within 48 hours.

Middle-sale Service
Testing quality again before sending goods.
Well-trained sales team for sales and basic technical service.
Online system software demo and configuration is available.
PDF specification sheet, system configuration template and architectural & engineer specification for documents support.
Sending the tracking number/bill of loading, and update the situations of the goods till customers receive the goods.

After-sale service
ITC guarantee all electronics of 3 years quality warranty.
ITC could supply 1% wearing spare parts free of charge.
Two English spoken technician provide online after sales service.
Technical documents could be downloaded from website www.itc-pa.com.cn.
All of the quality compliant shall be feedback with a solution within 48 hours.
