- Place of Origin:CN;GUA
- Model Number:T-60DTBV
- Brand Name:ITC
- Rated Power Output:60W/120W/240W
- Speaker Output:100V
- Frequency Response:80Hz~16KHz(+1dB,-3dB)
- S/N Ratio:MIC1, 2, 3:66dB; AUX1, 2:80dB
- THD:Less than 0.5% at 1KHz, 1/3 rated power
- Mute:EMC has highest priority
- Protection:Over-heat, overload, short circuit, etc
- Power Supply:~220-240V /50Hz
- Dimension:484*295*44mm
- Certificate:CCC CE
T-60DTBV DC 24V Available 60W Public Address Mixer Amplifier With MP3/Tuner/Bluetooth
Product Introduction
It is the mixer amplifier with mp3/TUNER/Bluetooth for small and medium sized background music occasion such as small supermarkets, shopping malls, and cafes.
Features
* Standard rack mounted design (1U), SMT technology.
* Support mp3/TUNER/Bluetooth remote control function, and the remote control distance is up to 8 m.
* With USB interface and SD card interface, integrated MP3 player module, with automatic priority playing audio function, and digital screen can display the currently playing music of USB
* Integrated Bluetooth module to support to play music via Bluetooth mobile phone.
* Integrated TUNER module, with FM radio antenna port.
* 1 channel EMC input, 2 channels AUX input, 4 channels MIC input.
* Channel priority: EMC >MIC1>MIC2, MIC3, AUX1, AUX2
* Each channel has independent volume control function; master input has volume control and treble/bass control
* The machine is equipped with level indication, overload and protection indicator.
* The device has good self-protection such as short circuit, overload and overheating.
* Two output modes: constant voltage output 100V, 4-16Ω.
* Energy-efficient switching power supply combines with energy-saving and ultra-stable design of Class D amplifiers
* Wide voltage supply: 220V-240V can work normally; Support backup power supply 24V no delay switching.
Specification
Model | T-60DTBV | T-120DTBV | T-240DTBV | ||||||
Output Terminal | 100V | ||||||||
Output Power | 60W | 120W | 240W | ||||||
The Input Sensitivity And Impedance | MIC1, 2, 3, 4input:5mV/600Ω Unbalanced 6.3 connector | ||||||||
AUX1, 2 input:350mV/10KΩ Unbalanced RCA connector | |||||||||
EMC input:775mV/10KΩ Unbalanced 6.3 connector | |||||||||
The Output Sensitivity & Source Impedance | MIX OUT:1000mV/470Ω Unbalanced RCA connector | ||||||||
Tone | Bass: ±10dB at 100Hz | ||||||||
Treble: ±10dB at 10KHz | |||||||||
Frequency Response | 80Hz~16KHz(+1dB,-3dB) | ||||||||
SNR | MIC1, 2, 3:66dB; AUX1, 2:80dB | ||||||||
THD | Less than 0.5%( at 1KHz, 1/3 rated power) | ||||||||
Mute Control | EMC has highest priority | ||||||||
MIC 1 priority over MIC2-4, AUX1-2 audio input, | |||||||||
Channel Crosstalk Attenuation | ≥50dB | ||||||||
Heat Dissipation | Flank in and rear panel out to force fan cooling, fan starts when amplifier turned on, infinitely variable speeds | ||||||||
Protection | Over-heat, overload, short circuit, etc | ||||||||
Power Supply | ~220-240V /50Hz | ||||||||
Power Consumption | 120W | 180W | 300W | ||||||
Dimension | 484×295×44mm | ||||||||
Weight | 4.3Kg | 4.5Kg | 5.1Kg | ||||||
ITC Audiovisual is the pioneer of Chinese audiovisual industry. Latest, we launch Luna Cloud-based Public Address System. Also, we develop steadily. We provide our client with one-stop solution, such as Public Address System,IP System,conference system,video conferencing,Evacation System, professional sound system, multimedia central control system, etc. What's more,our system is applied to various world-class events, such as 2008 Peking Olympic Games, 2010 Shanghai Expo, 2010 Guangzhou AsianGames, etc. For now,we have up to 200 thousand successful cases in China and in worldwide.
Q1: Are you manufacturer or trade company? Where?
A: We are manufacturer. which located in NO. 1 Building B Block Zhongcun Street Panyu District Guangzhou, Guangdong, China.
Q2: Do you offer OEM&ODM service?
A: Yes, we do.
Q3: What's the quality standard of your products?
A: Our products has approved CCC, ISO9001, CE, RoHS, EN54-24 and EN54-16 certification.
Q4: Which place will use ITC equipment?
A: Our products are widely used in International Conference, Governments, Banks, Churches, Highways, Airports, Parliaments, Eduction institutes, Hotel, Private corporate conference hall and ect.
Q5: What project you have done in overseas?
A: *EXPO 2016 Antalya in Turkey
*International Airpport in Tabatinga, Brazil.
*The 7th South China Sea International Conference in Vietnam.
*The Subway center of Chanakyapri in New Delhi, India .
*Department of Public Works and Highway in Philippines.
Q6: How to contact us?
A: Write down what you need and click Send, you will get the feedback soon.
