- Place of Origin:CN;GUA
- Model Number:TI-350B/TI-550B/TI-650B
- Brand Name:ITC
- Type:PROFESSIONAL AMPLIFIER
- Channels:5 (4.1)
- RMS:350W/500W/650W
- Speaker Outputs:70V, 100V & 4~16Ω
- Output Sensitivity:1000mV
- Impedance:470Ω
- Tone:Bass: ±10dB at 100Hz, Treble: ±10dB at 10KHz
- Frequency Response:50Hz~16KHz(+1dB, -3dB)
- THD:Less than 0.5%
- Gain Control:±2.5mV~±75mV at 30dB
- Crosstalk: ≤50dB
- Phantom Power:+48V
ITC TI-650B 350W 500W 650W 5 Zone Mixer BGM Amplifier with Mic Input
Features
* Rated power from 60W, 120W, 240W, 350W, 500W to 650W
* 2U rack mount (less than 350W) and 3U rack mount design
* 70V, 100V and low impedance 4-16 ohm speaker output
* 5 zone and all zone speaker terminals
* Three balanced Mic inputs
* Mic 1(phone jack) with VOX priority and VOX level on front panel
* Mic 2-3 by XLR type on rear panel with phantom power
* Two Aux Inputs and 2 line inputs for spare use
* One EMC priority input
* EMC has priority over all inputs except MIC1
* Mic 1-3, Aux 1-2 and master volume controls and bass/treble tone control
* Short circuit, overload and high temp protection
.........................................................................................................................................
Descriptions
5 Zone Mixer Amplifier with XLR Balanced MIC Input and Phantom Power
The basic public address 5 zone mixer amplifiers have power ratings from 60W, 120W, 240W, 350W, 500W to 650W. They are featured of 3 balanced microphone inputs, 2 aux inputs and 1 EMC input. Priority muting is achieved via EMC for overriding other inputs except Mic1 on front panel. Individual gain controls are provided for Mic 1-3 and Aux 1-2, bass and treble controls and master volume control are provided for overall tone control. 70V, 100V and low impedance 4-16ohms speaker outputs are provided. Extensive protection from short-circuit, overload and high temp.
Optional
* DC 24V available on less than 500W models
* Panel with/without handhold
* Faults monitoring module, it can output short circuit signal to achieve main/spare amplifier switch
Model | TI-350B | TI-550B | TI-650B |
Rated Power Output | 350W | 500W | 650W |
Speaker Outputs | 70V, 100V & 4~16Ω | ||
Input Sensitivity & Impedance | MIC 1, 2, 3: 5mV/600Ω, Unbalanced phone jack input MIC 2, 3: ±2.5mV/2KΩ, Balanced XLR input MIC 2, 3: 775mV/10KΩ, Unbalanced RCA input AUX 1, 2: 350mV/10KΩ, Unbalanced RCA input EMC: 775mV/10KΩ, Unbalanced RCA input | ||
Output Sensitivity & Impedance | MIX OUT: 1000mV/470Ω, Unbalanced RCA output | ||
Tone | Bass: ±10dB at 100Hz, Treble: ±10dB at 10KHz | ||
Frequency Response | 50Hz~16KHz(+1dB, -3dB) | ||
S/N Ratio | MIC 1, 2, 3: 66dB, AUX 1, 2: 80dB | ||
THD | Less than 0.5% at 1KHz, 1/3 rated power | ||
Muting Function | MIC 1 overrides other input signals with 0-30dB attenuation | ||
Gain Control | ±2.5mV~±75mV at 30dB | ||
Crosstalk | ≤50dB | ||
Phantom Power | +48V, with LED indicator | ||
Cooling | Fan automatically start up when temp reaches 55°C | ||
Protection | High temp, overload & short-circuit | ||
Power Supply | ~110V/60Hz or ~230V/50Hz or DC 24V | ||
Power Consumption | 500W | 750W | 950W |
Weight | 18.9Kg | 22.6Kg | 23.9Kg |
Dimensions | 484x385x132mm | ||
Finish | Panel: aluminum plate, black Case: steel plate, black | ||
ITC Audiovisual is the pioneer of Chinese audiovisual industry. Latest, we launch Luna Cloud-based Public Address System. Also, we develop steadily. We provide our client with one-stop solution, such as Public Address System,IP System,conference system,video conferencing,Evacation System, professional sound system, multimedia central control system, etc. What's more,our system is applied to various world-class events, such as 2008 Peking Olympic Games, 2010 Shanghai Expo, 2010 Guangzhou AsianGames, etc. For now,we have up to 200 thousand successful cases in China and in worldwide.
